UL 2085 Fireguard

UL 2085 Fireguard is available in cylindrical and rectangular.
We offer various cylindrical UL 2085 (Fireguard) tanks certified by STI (Steel Tank Institute). Sizes available from 300 gallons to 25,000 gallons. We offer two separate support packages: Saddle support and Skid support.
UL 2085 Fireguard tanks are STI (Steel Tank Institute) certified and come with a 30-year warranty.

Rectangular

Tank Gallons
Tank Inside Dims
Tank Outside Dims
Weight
CFH
Annular CFH
Tank Chart
300G
54" x 38" x 36"
66" x 50" x 48"
2,800 LBS
63,200
105,000
View Chart
500G
60" x 50" x 40"
72" x 62" x 52"
3,200 LBS
86,320
134,400
View Chart
1K
98" x 56" x 43"
104" x 62.5" x 49"
5,800 LBS
136,500
165,900
View Chart
2K
132" x 60" x 60"
140" x 66.5" x 66.5"
8,000 LBS
219,400
241,600
View Chart
3K
180" x 60" x 65"
188" x 66.5" x 71"
11,000 LBS
260,840
282,480
View Chart
4K
180" X 72" X 72"
188" X 78" X 78"
16,000 LBS
284,320
306,400
View Chart
5K
176" x 87" x 76"
184" x 94" x 82"
18,000 LBS
304,320
327,540
View Chart
6K
240" x 78.5" x 74"
248" x 85" x 80"
20,000 LBS
336,360
360,720
View Chart
8K
278" x 88" x 76"
286" x 94" x 82"
24,000 LBS
375,280
398,840
View Chart
10K
346" x 88" x 76"
354" x 94" x 82"
30,000 LBS
417,200
441,940
View Chart
12K
360" x 88" x 88"
368" x 94" x 94"
34,000 LBS
451,120
475,330
View Chart

Cylindrical

Tank Gallons
Tank Inside Dims
Tank Outside Dims
Weight
CFH
Annular CFH
Tank Chart
1K
64" x 74"
70" x 86"
5,800 LBS
116,550
145,950
View Chart
2K
64" X 146"
70" X 158"
8,000 LBS
196,300
222,760
View Chart
3K
64" x 216"
70" x 228"
11,000 LBS
244,200
265,460
View Chart
4K
96" x 134"
102" x 146"
16,000 LBS
257,720
278,340
View Chart
4K LONG
64" x 288"
70" x 300"
16,000 LBS
281,100
304,320
View Chart
5K
96" x 168"
102" x 180"
18,000 LBS
282,940
305,280
View Chart
6K
96" x 194"
102" x 180"
20,000 LBS
302,400
324,340
View Chart
8K
96" x 278"
102" x 290"
24,000 LBS
358,560
380,220
View Chart
10K
96" x 324"
102" x 338"
30,000 LBS
385,920
409,640
View Chart
12K
96" x 386"
102" x 398"
34,000 LBS
421,520
444,660
View Chart
15K
96" x 482"
102" x 494"
37,000 LBS
472,230
496,100
View Chart
15K
120" x 314"
126" x 326"
37,000 LBS
439,560
462,620
View Chart
20K
114" x 462"
120" x 474"
46,000 LBS
514,080
532,085
View Chart
25K
120" x 516"
126" x 528"
58,000 LBS
545,615
559,700
View Chart
*ALL AVAILABLE IN MULTI-COMPARTMENT*
